Image Sensor
|
1/2.8 inch Progressive Scan CMOS
|
|
Min. Illumination
|
F1.5, AGC On: Color: 0.02 lux, B/W : 0.002 lux, 0 lux with IR
|
|
Max. Image Resolution
|
1920 x 1080
|
|
Focal Length
|
4.7-94.0mm, 20x
|
|
Digital Zoom
|
16x
|
|
Zoom Speed
|
Approx.3s (Optical Wide~Tele)
|
|
Angle of View
|
58.3-3.2 degree (Wide~Tele)
|
|
Min. Working Distance
|
10~1,000mm(Wide~Tele)
|
|
Aperture Range
|
F1.6~F3.5
|
|
Focus Mode
|
Auto/ Semiautomatic/ Manual
|
|
DWDR
|
Support
|
|
S/N Ratio
|
≥ 52dB
|
|
Shutter Time
|
1-1/10,000s
|
|
AGC
|
Auto/ Manual
|
|
White Balance
|
Auto/ Manual/ ATW/ Indoor/ Outdoor/ Daylight lamp/ Sodium lamp
|
|
Day & Night
|
IR Cut Filter
|
|
Privacy Mask
|
8 privacy masks programmable
|
|
Enhancement
|
3D DNR, Defog, HLC/BLC
|
|
Range
|
Pan: 360°endless; Tilt: -15°~90°(Auto Flip)
|
|
Speed
|
Pan Manual Speed: 0.1°~400°/s, Pan Preset Speed: 400°/s. Tilt Manual Speed: 0.1°~200°/s, Tilt Preset Speed: 200°/s
|
|
Number of Preset
|
300
|
|
Patrol
|
8 patrols, up to 32 presets per patrol
|
|
Park Action
|
Preset/ Patrol/ Pattern/ Pan scan/ Tilt scan/ Random scan/ Frame scan/ Panorama scan
|
|
Scheduled Task
|
Auto scan/ Frame scan/ Random scan/ Patrol/ Pattern/ Preset/ Panorama scan/ Tilt scan/ Dome reboot/ Dome adjust/ Aux output
|
|
Detection
|
Intrusion detection, Line crossing detection, Audio exception detection, Motion detection
|
|
ROI encoding
|
Support 4 areas with adjustable levels
|
|
IR Distance
|
Up to 150m
|
|
IR Intensity
|
Automatically adjusted, depending on the zoom ratio
|
|
Alarm I/O
|
2/1
|
|
Alarm Trigger
|
Intrusion detection, Line crossing detection, Audio exception detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
|
|
Alarm Action
|
Preset, Patrol, Pattern, Recording, Relay output, Upload center, Upload FTP, Email linkage
|
|
Audio Input
|
1 Mic in/Line in interface, line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
|
|
Audio Output
|
Preset, Patrol, Pattern, Recording, Relay output, Upload center, Upload FTP, Email linkage
|
|
Ethernet
|
10Base-T / 100Base-TX, RJ45 connector
|
|
Main Stream
|
50Hz: 25 fps (1920 x 1080), 25 fps (1280 x 720). 60Hz: 30 fps (1920 x 1080), 30 fps (1280 x 720)
|
|
Sub Stream
|
50Hz: 25fps (704 x 576), 25fps (352 x 288), 25fps (320 x 240); 60Hz: 30fps (704 x 480), 30fps (352 x 240), 30fps (320 x 240)
|
|
Image Compression
|
H.264/ MJPEG
|
|
Audio Compression
|
G.711ulaw/ G.711alaw/ G.726/ MP2L2/ G.722
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
|
|
Simultaneous Live View
|
Up to 20 users
|
|
Mini SD Memory Card
|
Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording
|
|
Web Browser
|
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +
|
|
Power
|
High-PoE&24 VAC, Max.32W
|
|
RS-485 Protocols
|
HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
|
Protection Level
|
IP66, TVS 4,000V lightning protection, surge protection and voltage transient protection
|
|
Dimensions
|
Φ185 x 330mm
|
|
Weight
|
4kg
|
