Image sensor
|
1/2.8 inch Progressive Scan CMOS
|
|
Effective pixel
|
2230K pixels
|
|
Min. Illumination
|
Color: 0.4lux (F1.6, 1/30 sec, 50 IRE, AGC on); 0.05lux (F1.6, 1/1 sec, 50 IRE, AGC on); 0 lux with IR. B/W: 0.03lux (F1.6, 1/30 sec, 50 IRE, AGC on); 0.005lux (F1.6, 1/1 sec, 50 IRE, AGC on); 0 lux with IR
|
|
White balance
|
Auto/ Manual/ ATW/ Indoor/ Outdoor/ Daylight lamp/ Sodium lamp
|
|
AGC
|
Auto/ Manual
|
|
S/N ratio
|
≥ 50dB
|
|
Digital noise reduction
|
3D DNR
|
|
Backlight compensation
|
HLC/ BLC
|
|
Wide dynamic range
|
Digital WDR
|
|
Day & Night
|
IR Cut Filter
|
|
Digital zoom
|
16X
|
|
Privacy masking
|
24 privacy masks programmable, optional multiple colors and mosaics
|
|
Focus mode
|
Auto/ Semiautomatic/ Manual
|
|
Enhancement
|
Defog
|
|
Focal length
|
4.7 ~ 94mm, 20x optical zoom
|
|
Zoom speed
|
Approx. 2.7s (Optical Wide-Tele)
|
|
Angle of view
|
58.3 ~ 3.2 degree (Wide-Tele)
|
|
Min. Working distance
|
10 ~ 1500mm (Wide-Tele)
|
|
Aperture range
|
F1.6 ~ F3.5
|
|
Smart tracking
|
Support
|
|
Pan/ Tilt range
|
Pan: 360° endless; Tilt: -2° ~ 90° (auto flip)
|
|
Pan / Tilt speed
|
Pan Manual Speed: 0.1° ~ 160°/s, Pan Preset Speed: 240°/s. Tilt Manual Speed: 0.1° ~ 120°/s, Tilt Preset Speed: 200°/s
|
|
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples
|
|
Number of preset
|
256
|
|
Patrol
|
8 patrols, up to 32 presets per patrol
|
|
Pattern
|
4 patterns, with the recording time not less than 10 minutes per pattern
|
|
Power-off memory
|
Support
|
|
Park action
|
Preset/ Patrol/ Pattern/ Pan scan/ Tilt scan/ Random scan/ Frame scan/ Panorama scan
|
|
PTZ position display
|
Support
|
|
Preset freezing
|
Support
|
|
Scheduled task
|
Preset/ Patrol/ Pattern/ Pan scan/ Tilt scan/ Random scan/ Frame scan/ Panorama scan/ Dome reboot/ Self-test action/Alarm output
|
|
Smart IR
|
Support
|
|
IR distance
|
Up to 150m
|
|
IR intensity
|
Automatically adjusted, depending on the zoom ratio
|
|
Alarm input
|
7 inputs
|
|
Alarm output
|
2 relay outputs, alarm response actions configurable
|
|
Alarm trigger
|
Motion detection, Audio Exception Detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
|
|
Alarm action
|
Preset, Patrol, Pattern, SD/SDHC card recording, Relay output, Notification on Client
|
|
Video output
|
1.0V[p-p]/ 75Ω, NTSC (or PAL) composite, BNC
|
|
Audio input
|
1 Mic in/Line in interface. Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
|
|
Audio output
|
1 Audio output interface. Line level, impedance: 600Ω
|
|
Ethernet
|
10Base-T/ 100Base-TX, RJ45 connector
|
|
Max. image resolution
|
1920 x 1080
|
|
Frame rate
|
50Hz: 25 fps (1920 x 1080), 25 fps (1280 x 960), 25 fps (1280 x 720). 60Hz: 30 fps (1920 x 1080), 30 fps (1280 x 960) , 30 fps (1280 x 720)
|
|
Image compression
|
H.264/ MJPEG/ MPEG4, H.264 encoding with Baseline/ Main/ High profile
|
|
Audio compression
|
G.711u / G.711a / G.726 / MP2L2
|
|
Simultaneous live view
|
Up to 10
|
|
Streams
|
Triple streams
|
|
SD memory card
|
Built-in SD/SDHC Slot, up to 32GB, support manual/ alarm/ edge recording
|
|
Application programming
|
Open-ended API, support Onvif, PSIA and CGI
|
|
RS-485 protocols
|
HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
|
Power
|
24VAC
|
|
Protection level
|
IP66, TVS 4000V lightning protection, surge protection and voltage transient protection
|
|
Dimensions
|
Φ245 x 399mm
|
|
Weight
|
5.5kg
|
