| Camera |
| Image Sensor |
1/2.8 inch Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 lux @ (F1.2, AGC ON), 0 lux with IR |
| Day & Night |
ICR Switch |
| Focus Mode |
Auto/Semi-Auto/Manual |
| Shutter Speed |
1/1 to 1/10,000s |
| Digital Zoom |
16x |
| White Balance |
Auto/manual/ATW (auto tracking white balance)/indoor/outdoor/daylight |
| lamp/sodium lamp |
| AGC |
Auto/Manual |
| Backlight Compensation |
Support |
| Wide Dynamic Range |
Support |
| DNR (Digital NoiseReduction) |
Support |
| Privacy Mask |
8 programmable privacy masks |
| Lens |
| Focal Length |
4.7 to 94mm, 20x |
| Field of View |
61.4° to 2.9° (wide-tele) |
| Working Distance |
10 to 1000mm (wide-tele) |
| Zoom Speed |
Approx. 3s (optical lens, wide-tele) |
| Aperture Range |
F1.6 to F3.5 |
| Smart |
| Smart Detection |
Intrusion detection, line crossing detection, audio exception detection, motion detection, and video tampering detection |
| Smart Recording |
Edge storage, smart search in smart NVR, and VCA playback |
| Smart Image Enhancement |
WDR, HLC, Defog, EIS |
| Smart Encoding |
Low bitrate, and ROI (Region of Interest) encoding |
| Smart Alarm |
Alarm for network disconnection, IP address conflict, HDD full, HDD error, and illegalLogin |
| Network |
| Main Stream |
50Hz: 25fps (1920 x 1080, 1280 x 960, 1280 x 720), 50fps (1280 x 960, 1280 x 720) |
| 60Hz: 30fps (1920 x 1080, 1280 x 960, 1280 x 720), 60fps (1280 x 960,1280 x 720) |
| Sub-Stream |
50Hz: 25fps (704 x 576, 640 x 480, 352 x 288) |
| 60Hz: 30fps (704 x 480, 640 x 480, 352 x 240) |
| Third Stream |
50Hz: 25fps (1920 x 1080, 1280 x 960,1280 720,704 x 576, 640 x 480, 352 x 288) |
| 60Hz: 30fps (1920 x 1080,1280 x 960,1280 x 720,704 x 480, 640 x 480, 352 x 240) |
| Video Compression |
H.264/MJPEG |
| Audio compression |
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour |
| Simultaneous Live View |
Up to 20 users |
| User/Host |
Up to 32 users, 3 levels: Administrator, Operator, and User |
| Security Measures |
User authentication (ID and PW), host authentication (MAC address), IP addressfiltering, HTTPS encryption and IEEE 802.1x port-based network access control |
| Pan and Tilt |
| Movement Range |
Pan: 360°, Tilt: 5° to 90° |
| Movement Speed |
Pan: 0.1° to 160°/s, Tilt: 0.1°to 120°/s |
| Preset No. |
300 |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Park Action |
Preset/ patrol/ pattern/ auto scan/ tilt scan/ random scan/frame scan/panorama scan |
| Scheduled Task |
Preset/ patrol/ pattern/ auto scan/ tilt scan/ random scan/ frame scan/ panorama scan/dome reboot/ dome adjust/ aux output |
| Proportional Zoom |
Support |
| Power-off Memory |
Support |
| Position Display |
On/ Off |
| System Integration |
| Alarm I/O |
1 alarm input, 1 alarm output |
| Alarm Linkage |
Alarm actions, such as Send Email, Notify Surveillance Center, Upload to FTP/MemoryCar/NAS, Trigger Recording etc. |
| Audio I/O |
1 audio input, 1 audio output |
| Ethernet |
1 RJ45 10M/100M Ethernet interface |
| Memory Card |
Built-in memory card slot, supporting SD/SDHC/SDXC, up to 128GB |
| Client |
iVMS-4200 |
| Web Browser |
IE7+, Chrome18+, Firefox 5.0+, Safari 5.02+ |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply |
24VAC, and PoE (802.3at) |
| Max.: 18W |
| Power Consumption |
Max. 12W |
| Weather Proof |
IP66 |
| Dimensions |
Φ179.4 x 239.5mm |
| Weight |
Approx. 2.0kg |
