| Camera |
| Image Sensor |
1/2.7 inch Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter time |
1/3s ~ 1/100,000s |
| Lens |
2.8 - 12 mm @ F1.4, Angle of view: 113°-33.8° |
| Lens Mount |
φ14 |
| Adjustment Range |
Pan: 0° to 360°, Tilt: 0° to 100°, Rotation: 0° to 360° |
| Day & Night |
IR cut filter with auto switch |
| Wide Dynamic Range |
Digital WDR |
| Digital noise reduction |
3D-DNR |
| Compression Standard |
| Video Compression |
H.264/MJPEG |
| H.264 code profile |
BaseLine Profile/Main Profile |
| Video bit rate |
32Kbps~8Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate |
64Kbps(G.711)/ 16Kbps(G.722.1) / 16Kbps(G.726) /32-128Kbps(MP2L2) |
| Dual Stream |
Yes |
| Image |
| Max. Image Resolution |
1920 x 1080 |
| Frame Rate |
50Hz: 25fps (1920 x 1080), 25fps (1280 x 960), 25fps (1280 x 720) |
| 60Hz: 30fps (1920 x 1080), 30fps (1280 x 960), 30fps (1280 x 720) |
| Image Settings |
Saturation, brightness, contrast adjustable through client software or web browser |
| BLC |
Yes, zone configurable |
| ROI |
Support |
| Network |
| Network Storage |
Built-in Micro SD/ SDHC/ SDXC slot, up to 128G, NAS (NFS, SMB/ CIFS) |
| Alarm Trigger |
Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| System Compatibility |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100Mbps Ethernet interface |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply |
12VDC ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5.5 W |
| Impact Protection |
IK10 |
| Weather Proof |
IP67 |
| IR Range |
Approx 20 to 30 meters |
| Dimensions |
Φ141 x 99.9 mm |
| Weight |
800g |
